- R OLLER CHIZIQLI QO'LLANMA
- C3 sharli vint
- Import qilingan nozik rulman
- Servo gidravlik minora
- Ixtiyoriy quvvat manbai
- Asbobni sozlash vositasi ixtiyoriy
|
Texnik xususiyatlari |
birlik |
TCK1000 |
Tck700 |
|
To'shak ustida suzing |
mm |
￠1100 |
￠700 |
|
Tashishdagi maksimal burilish diametri |
mm |
￠750 |
￠500 |
|
Maksimal ishlov berish uzunligi |
mm |
1000/1500/2000/3000/4000/5000 |
|
|
Shpindel boshi shakli |
mm |
A2-11 |
A2-11/8 |
|
Shpindel dvigatelining kuchi |
Kv |
30-37(Servo) |
22-30(Servo) |
|
Shpindelning maksimal tezligi |
r/min |
2000 |
2500 |
|
Milning teshik diametri orqali |
mm |
￠130 |
￠88/105/130 |
|
Nishab burchagi |
DEG |
45 daraja |
45 daraja |
|
Harakatlanuvchi masofa x |
mm |
500 |
350 |
|
Tez harakat tezligi X/Z |
m/min |
16/24 |
16/24 |
|
Servo motor momenti X/Z |
N.m |
22/22(30) |
22/22 |
|
Turiet shakli |
mm |
12 stantsiyali servo/gidravlik (ixtiyoriy quvvatli asbob minorasi) |
|
|
Asbob o'lchami (burilish / burg'ulash) |
mm |
32*32/￠50 |
32*32/￠40 |
|
Chuck hajmi |
mm |
15"/18"/21" |
10"/12"/15"/18" |
|
Joylashuvni aniqlashning aniqligini takrorlang |
mm |
±0.004 |
±0.004 |
|
Taglik yengi diametri |
mm |
￠80/200 |
￠150/150 ichki aylanish |
|
Yengidagi konusli teshik |
MT |
6 |
5/6 |
|
O'lchamlari |
m |
4.7/5.9/6.6*2.1*2.2 |
4.6/5.8/6.5*2.2*2.3 |
|
Mashinaning og'irligi (taxminan) |
T |
9/11/13/16 |
7.5/9/10.5/12 |
